THERMODYNAMICS ASSIGNMENT EC41FA

Submitted to:

Engr. Joel Gatchalian

Date Submitted: July 28, 2011

NAMES:

 Almarez, Melvin  Balisi, Baby Liezel  Claravall, Justine  Jarabe, Crystel Ann  Jose, Michell Anne  Mercene, Ma. Laeka Ann  Sarmiento, Czarina Jean  Talavera, Jayson D.

Solution:

2. A reciprocating compressor draws in 500 cubic feet per minute of air whose density is 0.079 lb/cu.ft and discharges it with a density of 0.304 lb/cu.ft. At the suction, p 1 =15 psia; at discharge, p 2 = 80 psia. The increase in the specific internal energy is 33.8 Btu/lb and the heat transferred from the air by cooling is 13 Btu/lb. Determine the work on the air in Btu/min and in hp. Neglect change in kinetic energy.

3. Steam enters a turbine with an enthalpy of 1292 Btu/lb and leaves with an enthalpy of 1098 Btu/lb. The transferred heat is 13 Btu/lb. What is the work in Btu/min and in hp for a flow of 2 lb/sec?

4. A thermodynamic steady flow system receives 4.56 kg per min of a fluid where p 1 =137.90 kPa, v 1 =0.0388 m^3 /kg, Ѵ 1 =122 m/s, and u 1 =17.16 kJ/kg. The fluid leaves the system at a boundary where p 2 =551.6 kPa, v 2 =0.193 m^3 /kg, Ѵ 2 =183 m/s and u 2 =52.80 kJ/kg. During the passage through the system the fluid receives 3000 J/s of heat. Determine the work.

Solution:

5. Air flows steadily at the rate of 0. kg/s through an air compressor, entering at 7 m/s speed, 100 kPa pressure and 0.95 m^3 /kg specific volume, and leaving at 5 m/s, 700 kPa, and 0.19 m^3 /kg. The internal energy of the air leaving is 90 kJ/kg greater than that of the air entering. Cooling water in the compressor jackets absorbs heat from the air at the rate of 58 kW. Compute the work in kW.

Solution:

6. In a steady flow apparatus, 135 kJ of work is done by each kg of fluid. The specific volume of the fluid, pressure, and speed at the inlet are 0.37 m^3 /kg, 600 kPa, and 16 m/s. The inlet is 32 m above the floor, and the discharge pipe is at the floor level. The discharge conditions are 0. m^3 /kg, 100 kPa, and 270 m/s. The total heat loss between the inlet and discharge is 9 kJ/kg of fluid. In flowing through this apparatus, does the specific internal energy increase or decrease, and by how much?

Solution:

7. Steam enters a turbine stage with an enthalpy of 3628 kJ/kg at 70 m/s and leaves the same stage with an enthalpy of 2846 kJ/kg and a velocity of 124 m/s. Calculate the work done by the steam.

Solution:
