Database Tuning and Physical Design:
Query Optimization, Index Selection, and
Schema, Query, and Transaction Tuning
David Toman
School of Computer Science
University of Waterloo
Introduction to Databases CS348
David Toman (University of Waterloo) DB Tuning 1 / 15
pf3
pf4
pf5
pf8
pf9
pfa
pfd
pfe
pff

Partial preview of the text

Download Database Tuning: Query Optimization, Index Selection, and Schema Design and more Slides Introduction to Database Management Systems in PDF only on Docsity!

Database Tuning and Physical Design:

Query Optimization, Index Selection, and

Schema, Query, and Transaction Tuning

David Toman

School of Computer Science University of Waterloo

Introduction to Databases CS

Database Tuning

Goal

Make a set of applications execute “as fast as possible”.

  • (^) optimize for response time?
  • optimize for overall throughput?

How can we affect performance (as DBAs)?

  • (^) make queries run faster (data structures, clustering, replication)
  • make updates run faster (locality of data items)
  • (^) minimize congestion due to concurrency

How does it Search for Plans?

Query equivalence is undecidable!!

  • always good transformations, e.g.,

A=:p (R on S ) 7! (A=:p (R)) on S

  • rewrites using integrity constraints
  • (^) cost-based access path selection and join ordering ... the query optimizer may not find the right plan (query tuning)

Cost Models for Query Optimization

How do we figure out how fast a particular plan is??

For every stored relation R with an attribute A we keep:

  • jRj: the cardinality of R (the number of tuples in R)
  • b(R): the blocking factor for R
  • min(R; A): the minimum value for A in R
  • max(R; A): the maximum value for A in R
  • distinct (R; A): the number of distinct values of A

) in practice much more complex statistics are kept

Based on these values we try to estimate the cost of query plans ) costs estimated in number of disk I/O operations

Strategy 1: Use CourseInd

Assuming uniform distribution of tuples over the courses, there will be about jMarkj/100 = 100 tuples with Course = PHYS.

Searching the CourseInd index has a cost of 2. Retrieval of the 100 matching tuples adds a cost of 100 =b(Mark) data blocks.

The total cost of 4.

Selection of N tuples from relation R using a clustered index has a cost of 2 + N =b(R).

Strategy 2: Use StudnumInd

Assuming uniform distribution of tuples over student numbers, there will be about jMarkj/500 = 20 tuples for each student.

Searching the StudnumInd has a cost of 2. Since this is not a clustered index, we will make the pessimistic assumption that each matching record is on a separate data block, i.e., 20 blocks will need to be read.

The total cost is 22.

Selection of N tuples from relation R using a non-clustered index has a cost of 2 + N.

Query Plan Tools (EXPLAIN)

How do we know what plan is used (and what the estimated cost is)? ) db2expln and dynexpln tools

select name from author, wrote where aid=author

(without index)

Estimated Cost = 50 Estimated Cardinality = 120 Optimizer Plan: RETURN | MSJOIN /
TBSCAN TBSCAN | | SORT SORT | | TBSCAN TBSCAN | | Table: Table: AUTHOR WROTE

(index on wrote(author))

Estimated Cost = 25 Estimated Cardinality = 120 Optimizer Plan: RETURN | MSJOIN /
TBSCAN IXSCAN | /
SORT Index: Table: | AW WROTE TBSCAN | Table: AUTHOR

More complex Designs

Multi-attribute Indices complex search/join conditions (in lexicographical order!) index-only plans (several clustered indices)

Join Indices allow replacing joins by index lookups

Materialized Views allow replacing subqueries by index lookups

Problem 1

how does the query optimizer know if/where to use such indices/views?

Problem 2

balance between cost of rematerialization and savings for queries.

Index Selection and Tools Example

rees$ db2advis -d cs -s "select name from author,wrote where aid=author" Calculating initial cost (without recommmended indexes) [25.390385] Initial set of proposed indexes is ready. Found maximum set of [2] recommended indexes Cost of workload with all indexes included [0.364030] timerons total disk space needed for initial set [ 0.014] MB total disk space constrained to [ -1.000] MB 2 indexes in current solution [ 25.3904] timerons (without indexes) [ 0.3640] timerons (with current solution) [%98.57] improvement Trying variations of the solution set. -- -- execution finished at timestamp 2006-11-23-12.25.24. -- -- LIST OF RECOMMENDED INDEXES -- =========================== -- index[1], 0.009MB CREATE INDEX WIZ8 ON "DAVID "."AUTHOR" ("AID" ASC, "NAME" ASC) ; -- index[2], 0.005MB CREATE INDEX AW ON "DAVID "."WROTE" ("AUTHOR" ASC) ; -- =========================== Index Advisor tool is finished.

) can be fed a workload instead of a single query

Schema Tuning and Normal Forms

So far we onlyadded data structures to improve performance. what to do if this isn’t enough?

Changes to the conceptual design

Goals:

  • (^) avoid expensive operations in query execution (joins)
  • retrieve related data in fewer operations

Techniques:

  • alternative normalization/weaker normal form
  • (^) co-clustering of relations (if available)/denormalization
  • vertical/horizontal partitioning of data (and views)
  • (^) avoiding concurrency hot-spots
