Arrays

1D Array Representation In Java, C, and C++

  • 1-dimensional array x = [a, b, c, d]
  • map into contiguous memory locations

Memory

a b c d

start

  • location(x[i]) = start + i

2D Arrays

The elements of a 2-dimensional array a declared as:

int [][]a = new int[3][4];

may be shown as a table

a[0][0] a[0][1] a[0][2] a[0][3] a[1][0] a[1][1] a[1][2] a[1][3] a[2][0] a[2][1] a[2][2] a[2][3]

Rows Of A 2D Array

a[0][0] a[0][1] a[0][2] a[0][3] row 0

a[1][0] a[1][1] a[1][2] a[1][3] row 1

a[2][0] a[2][1] a[2][2] a[2][3] row 2

2D Array Representation In Java, C, and C++

view 2D array as a 1D array of rows x = [row0, row1, row 2] row 0 = [a,b, c, d] row 1 = [e, f, g, h] row 2 = [i, j, k, l] and store as 4 1D arrays

2-dimensional array x a, b, c, d e, f, g, h i, j, k, l

2D Array Representation In Java, C, and C++

x.length = 3 x[0].length = x[1].length = x[2].length = 4

a b c d e f g h

i j k l

x[]

Array Representation In Java, C, and C++

  • This representation is called the array-of-arrays representation.
  • Requires contiguous memory of size 3, 4, 4, and 4 for the 4 1D arrays.
  • 1 memory block of size number of rows and number of rows blocks of size number of columns

a b c d e f g h

i j k l

x[]

Row-Major Mapping

  • Example 3 x 4 array:

a b c d e f g h i j k l

  • Convert into 1D array y by collecting elements by rows.
  • Within a row elements are collected from left to right.
  • Rows are collected from top to bottom.
  • We get y[] = {a, b, c, d, e, f, g, h, i, j, k, l}

row 0 row 1 row 2 … row i

Space Overhead

4 bytes for start of 1D array + 4 bytes for length of 1D array + 4 bytes for c (number of columns) = 12 bytes

(number of rows = length /c)

row 0 row 1 row 2 … row i

Disadvantage

Need contiguous memory of size rc.

Matrix

Table of values. Has rows and columns, but numbering begins at 1 rather than 0. a b c d row 1 e f g h row 2 i j k l row 3

  • Use notation x(i,j) rather than x[i][j].
  • May use a 2D array to represent a matrix.

Shortcomings Of Using A 2D

Array For A Matrix

  • Indexes are off by 1.
  • Java arrays do not support matrix operations such as add, transpose, multiply, and so on. - Suppose that x and y are 2D arrays. Can’t do x + y, x –y, x * y, etc. in Java.
  • Develop a class Matrix for object-oriented support of all matrix operations. See text.

Diagonal Matrix

  • x(i,j) is on diagonal iff i = j
  • number of diagonal elements in an n x n matrix is n
  • non diagonal elements are zero
  • store diagonal only vs n 2 whole Docsity.com

Lower Triangular Matrix

An n x n matrix in which all nonzero terms are either on or below the diagonal.

  • x(i,j) is part of lower triangle iff i >= j.
  • number of elements in lower triangle is 1 + 2 + … + n = n(n+1)/2.
  • store only the lower triangle
