All-Pairs Shortest Paths
Given an n-vertex directed weighted graph,
find a shortest path from vertex i to vertex j
for each of the n2 vertex pairs (i,j).
1
2
3
4
5
6
7
5
7 1 7
9
1
9
4
4
5 16
4
2
8
1
2
Docsity.com
pf3
pf4
pf5
pf8
pf9
pfa
pfd
pfe
pff
pf12
pf13
pf14
pf15
pf16
pf17
pf18
pf19
pf1a
pf1b
pf1c
pf1d

Partial preview of the text

Download All-Pairs Shortest Paths Algorithms: Dijkstra, Floyd-Warshall, and Decision Sequence and more Slides Computer Science in PDF only on Docsity!

All-Pairs Shortest Paths

  • Given an n-vertex directed weighted graph, find a shortest path from vertex i to vertex j for each of the n 2 vertex pairs (i,j).

1

2

3

4

5

6

7

5

7

(^1 )

9

1

9 4 4 5 16

4

2

8

2 1

Dijkstra’s Single Source Algorithm

  • Use Dijkstra’s algorithm n times, once with each of the n vertices as the source vertex.

1

2

3

4

5

6

7

5

7

(^1 )

9

1

9 4 4 5 16

4

2

8

2 1

Dynamic Programming Solution

  • Time complexity is Theta(n^3 ) time.
  • Works so long as there is no cycle whose length is < 0.
  • When there is a cycle whose length is < 0, some shortest paths aren’t finite.  If vertex 1 is on a cycle whose length is -2, each time you go around this cycle once you get a 1 to 1 path that is 2 units shorter than the previous one.
  • Simpler to code, smaller overheads.
  • Known as Floyd’s shortest paths algorithm.

Decision Sequence

  • First decide the highest intermediate vertex (i.e., largest vertex number) on the shortest path from i to j.
  • If the shortest path is i, 2, 6, 3, 8, 5, 7, j the first decision is that vertex 8 is an intermediate vertex on the shortest path and no intermediate vertex is larger than 8.
  • Then decide the highest intermediate vertex on the path from i to 8, and so on.

i j

Cost Function

  • Let c(i,j,k) be the length of a shortest path from vertex i to vertex j that has no intermediate vertex larger than k.

i j

c(i,j,n)

  • c(i,j,n) is the length of a shortest path from vertex i to vertex j that has no intermediate vertex larger than n.
  • No vertex is larger than n.
  • Therefore, c(i,j,n) is the length of a shortest path from vertex i to vertex j.

1

2

3

4

5

6

7

5

7

(^1 )

9

1

9 4 4 4

2

8

2 1

Recurrence For c(i,j,k), k > 0

  • The shortest path from vertex i to vertex j that has no intermediate vertex larger than k may or may not go through vertex k.
  • If this shortest path does not go through vertex k, the largest permissible intermediate vertex is k-1. So the path length is c(i,j,k-1).

i j

< k

Recurrence For c(i,j,k) ), k > 0

  • Shortest path goes through vertex k.

i j

k

  • We may assume that vertex k is not repeated because no cycle has negative length.
  • Largest permissible intermediate vertex on i to k and k to j paths is k-1.

Recurrence For c(i,j,k) ), k > 0

i j

k

  • Similarly, k to j path must be a shortest k to j path that goes through no vertex larger than k-1.
  • Therefore, length of i to k path is c(i,k,k-1), and length of k to j path is c(k,j,k-1).
  • So, c(i,j,k) = c(i,k,k-1) + c(k,j,k-1).

Recurrence For c(i,j,k) ), k > 0

  • Combining the two equations for c(i,j,k), we get c(i,j,k) = min{c(i,j,k-1), c(i,k,k-1) + c(k,j,k-1)}.
  • We may compute the c(i,j,k)s in the order k = 1, 2, 3, …, n.

i j

Space Reduction

  • c(i,j,k) = min{c(i,j,k-1), c(i,k,k-1) + c(k,j,k-1)}
  • When neither i nor j equals k, c(i,j,k-1) is used only in the computation of c(i,j,k). column k

row k

(i,j)

  • So c(i,j,k) can overwrite c(i,j,k-1).

Space Reduction

  • c(i,j,k) = min{c(i,j,k-1), c(i,k,k-1) + c(k,j,k-1)}
  • When i equals k, c(i,j,k-1) equals c(i,j,k).

 c(k,j,k) = min{c(k,j,k-1), c(k,k,k-1) + c(k,j,k-1)} = min{c(k,j,k-1), 0 + c(k,j,k-1)} = c(k,j,k-1)

  • So, when i equals k, c(i,j,k) can overwrite c(i,j,k-1).
  • Similarly when j equals k, c(i,j,k) can overwrite c(i,j,k-1).
  • So, in all cases c(i,j,k) can overwrite c(i,j,k-1).Docsity.com

Building The Shortest Paths

  • Let kay(i,j) be the largest vertex on the shortest path from i to j.
  • Initially, kay(i,j) = 0 (shortest path has no intermediate vertex).

for (int k = 1; k <= n; k++) for (int i = 1; i <= n; i++) for (int j = 1; j <= n; j++) if (c(i,j) > c(i,k) + c(k,j)) {kay(i,j) = k; c(i,j) = c(i,k) + c(k,j);}

Example

  • 7 5 1 - - - -
        • 4 - - -
  • 7 - - 9 9 - -
  • 5 - - - - 16 -
      • 4 - - - 1
            • 1 - 2 - - - - - - 4
          • 2 4 -

1

2

3

4

5

6

7

5

7

(^1 )

9

1

9 4 4 5 16

4

2

8

2 1

Initial Cost Matrix c(,) = c(,,0)
